Under Vehicle Inspection System Surveillance System Fix Type

Customization:	Available
Under Vehicle System:	for Embassy,Hotel,Villa,Airport
Under Vehicle Inspection:	Without Stop The Vehicle

Basic Specifications

Model NO. SPV3300

Camera Sensor Line Scans CCD

Under Vehicle Camera Resolution 2048

Scanner Power Supply 24 VDC, 5A

Illumination LED

Scanner Size 1200mm * 350mm

Operating Temperature Range -40℃ to +70℃

Intelligent IO Control 1 Set

Display 22'' LCD

Transport Package Wooden Packing

Specification CE, ISO

Origin China

HS Code 903180909

Production Capacity 500 Sets/Month

Product Features

Multi-entrance management model for comprehensive vehicle entry/exit statistics.

Automatic digital line scan providing high-resolution undercarriage imaging.

High automation level designed for simple, user-friendly operation.

Wide vision system applicable to a broad variety of vehicles.

Scanning completed during vehicle maneuvers without requiring stops.

Undercarriage images can be stored, retrieved, searched, and compared.

Diverse image processing features: zoom, stretch, and cut capabilities.

Associative storage via optional ALPR (Automatic License Plate Recognition) & RFID.

Key System Advantages

Supports scanning speeds up to 50 km/h with no parking required.
Comprehensive undercarriage image display directly on the monitoring screen.
Allows operators to easily zoom, crop, and save scanned images.
Engineered specifically to inspect the under-vehicle areas of diverse vehicle types.
Rapidly and accurately detects threats, contraband, or hidden personnel.
Significantly optimizes vehicle inspection speed while minimizing personnel overhead.

Technical Specifications

Category	Details
System Features	• Automatic digital line scan camera for high-resolution, distortion-free images. • Full-scan imaging under the vehicle showing objects down to 2mm in diameter. • Configurable inspection processes adapting to varying site demands. • Multi-scene image monitoring, storage, and recording. • Multi-language user interface support. • Strong system scalability for seamless control linkage. • Optional features: Automatic License Plate Recognition (ALPR) & multi-device networked control.
Embedded Screening Unit	Camera Sensor: Line Scan CCD Resolution: 5000 * 2048 pixels Power Supply: 24VDC, 3A Illumination: LED, Power: 24VDC, 150W Physical Dimensions: 1200mm x 350mm Storage Temperature Range: -25℃ to +70℃
Controller Unit	Input: 2 channels induction coil Output: 1 Channel switch type 12VDC Communication Port: RS485, Ethernet (Optional) Operating Temperature: -10ºC to 55ºC
System Host	CPU: Intel® Core™ 2 Duo CPU or higher Memory: 2GB (Optional 4GB) Graphics: Integrated Graphics Engine Gen 5.0 Hard Disk: SATA2 Hard Disk 500GB Network: Dual LAN (At least one Intel Gigabit) I/O: USB2.0 (Up to 4 ports) Monitor: 22-inch LCD (Resolution up to 19201080) Scene Video Record:* 4 channels (Compression algorithm: H.264)

Product Gallery

Under Vehicle Inspection System Surveillance System Fix Type

Frequently Asked Questions

1. What is the main application of this Under Vehicle Inspection System?

This system is primarily adopted to inspect the underside of a wide variety of vehicles to quickly and accurately identify hidden threats, contraband, or unauthorized persons without disrupting traffic flow.

2. Does the vehicle need to stop completely for the inspection scan?

No, the system is designed to complete full scanning while the vehicle maneuvers through the checkpoint. It can scan vehicles moving at speeds up to 50 km/h.

3. What is the camera resolution and scanning speed capability?

The embedded screening unit features an automatic digital line scan CCD camera providing a high image resolution of up to 5000*2048 pixels. This ensures clear, distortion-free images where objects down to 2mm in diameter are visible.

4. Can license plate information be recorded along with the vehicle scans?

Yes. The system supports optional integration with Automatic License Plate Recognition (ALPR) and RFID technology, enabling the associative storage of vehicle details alongside the matching undercarriage scans.

5. What is the standard lead time for order fulfillment?

If the items are in stock, the lead time is typically 3-5 days. For custom configurations or out-of-stock items, the production cycle ranges between 10-15 days. Delivery is flexible via air or sea freight depending on your preference.

6. What warranty and post-purchase technical support are provided?

We offer a comprehensive one-year warranty along with lifetime technical support. Additionally, we provide free training at our factory, with the option to deploy engineers to your location for onsite training at an extra charge.
