2024 D9EV EV Diagnostic Scanner for Tesla for BYD Energy Electric Vehicles High Voltage System Battery Pack Analysis Tool
2024 XTOOL D9EV EV Diagnostic Scanner For Tesla For BYD Energy Electric Vehicles High Voltage System Battery Pack Analysis Tool
XTOOL D9 EV is A Professional Ev Smart Diagnostic System, Making The Scanner Possible To Diagnose New Energy Vehicles, Including For Tesla, For Byd, For Bmw, For Vw, For Au-Di, Etc. This Automobile Diagnostic Scanner Combines Together Almost Every High-End Diagnostic Feature You Can Think Of, Bringing Repair Stores More Orders.
XTOOL D9 EV Equipped With A 9.7-Inch High-Performance Long-Lasting Tablet. The System Supports Bluetooth Communication, Doip Protocol, And Can-Fd Protocol. N9ev Supports Most Ev Models In The Market, And All The Software Including App, Diagnostic Software, And Operating System Support Online Updates. N9ev Covers Extensive Diagnostic Functions, Including Battery Pack Detection, Tesla Diagnosis, Reading Ecu Information, Reading/Clear Dtcs, Reading Live Data, And Immo Functions More Than 42+ Special Functions.
Key System Diagnostics & Capabilities
Smart Topology Module Mapping Capability
Visualize any abnormal modules/systems in your vehicle and their working status.
Battery Pack Test
Connected through OBD, Reading battery pack data through the port is simple to operate in this case. The OBD port has power supply and can perform complete diagnostic OBD testing. Departure test: After the battery is removed from the vehicle, the battery pack interface is used to read the electrical discharge test. Pool packet data needs to be connected to the lower computer through a jumper, and both the battery pack and the lower computer require external power supply.
Programmable Module Installation (PMI)
Essential Advanced Functions for Ford/Lincoln/Mazda Owners, upload the data from old module to the new module.
Advanced ECU Coding
Allow you to re-flash the Hidden Functions for personalization, Components Matching after making repairs or replacements, Reinforce Vehicle Performance, etc.
Support CAN FD & DoIP Protocol
For BUICK/CHEVROLET/ CADILLAC/GMC/HOLDEN/BMW/JAGUAR/LAND ROVER, etc, saving budget on buying adapters.
42+ Special Functions
Complete a wide array of maintenance functions, such as Camshaft Position Sensor Relearn, Throttle Body/Position Relearn, Zero-Point Calibration, Fuel Trim Reset, and more, which will help you LOWER your maintenance costs.
Powerful Key Programming capability
Read Pin code + Add New Keys (Fob/Smart)+ Remote Learning + Key Matching, ALL-KEYS-LOST, etc.
Full Bi-Directional Controls
Send the commands to the ECU and receive the response to perform the actuator tests include the pump / solenoid / injector to find problems and possible solutions.
Dealership Level Full System Diagnostics
Access ALL diagnostic capable vehicle system, Read/Clear Trouble Codes + 8-in-1 Live Data in Graphing/Text & Data Export/View + Retrieve Freeze Frame + Read ECU Information + Perform Active Tests to quickly locate the issue and troubleshoot it, saving you from missing work in time and going to the dealer.
Product Highlights
OE-Level Full System Diagnostics
Bi-Directional Control/Active Tests
Smart AutoVin & Auto Scan
Smart Topology Module Mapping Capability
Advanced ECU Coding
Battery Pack Test
Programmable Module Installation (PMI)
Powerful Key Programming capability
Stable Wireless BT Connectivity
42+ Special Functions
Support CAN FD & DoIP Protocol
Wide Vehicle Coverage
Android 10.0 OS + Dual-Band WIFI Frequency
3-Year Free Updates
Technical Specifications
Parameter
Details
Operating System
Android 10
Processor
4 Core 1.80GHz
Memory
2G RAM, 128 ROM
Display
9.7-inch capacitive touch screen with 1024×768P resolution
Connectivity
BT, WIFI 2.4/5G Hz, USB (Bluetooth / Wired)
Camera
Rear camera, 8.0 Megapixel, AF with Flashlight
Sensors
Gravity Accelerometer, Ambient Light Sensor
Auto Input/Output
Microphone, Dual Speakers
Battery
10000mAh, 3.7V lithium-polymer battery
Working Voltage
+ 9 ~ +36V
Input Voltage
12 V AC/DC power supply
Working Hours
12 hours
Operating Temp
-10 to 50℃
Storage Temp
-20 to 60℃
Humidity
<90%
Dimension (L×W×H)
313mm X 218mm X 30mm
Protocol Compatibility
CAN-FD, DoIP
Frequently Asked Questions
What models of electric vehicles (EVs) are supported by the XTOOL D9 EV?
The scanner supports most EV models in the market, including New Energy Vehicles such as Tesla, BYD, BMW, VW, Audi, etc.
How does the Battery Pack Test function work?
It supports two modes: OBD connection (simple operation through OBD port reading with built-in power supply) and Departure test (directly reading removed battery pack data via jumper connections to a lower computer, requiring external power supply for both components).
What communication protocols does the XTOOL D9 EV support?
The system supports Bluetooth communication, DOIP protocol, and CAN-FD protocol, which makes it compatible with Buick, Chevrolet, Cadillac, GMC, Holden, BMW, Jaguar, Land Rover, and more.
What are the main software update policies?
All software packages including the App, EV diagnostic software, and operating system support online updates. The scanner comes with 3-Year Free Updates.
What special maintenance functions can this tool perform?
It supports 42+ special maintenance functions such as Camshaft Position Sensor Relearn, Throttle Body/Position Relearn, Zero-Point Calibration, Fuel Trim Reset, and much more.
